Emulator E34 E36 E38 E39 E46 For BM-W EWS2 EWS3.2 is shipped with JUMPER 1 shorted. BM-W EWS2 EWS3.2 Emulator for testing purposes ISN 0579 is stored by default. Top 2 Reasons To Get BM-W EWS2 EWS3.2 Emulator 1. There are NO any counters or car starts limited. You can change and store new ISN without any limitations. 2. Emulator is shipped with JUMPER 1 shorted. For testing purposes ISN 0579 is stored by default. Notice: In case of EWS3.2 similar procedure is used, only difference is that that it is NOT connected directly to diagnostic K-line. Connection Picture: Installation: 1. Remove original EWS2 control unit, find 12v ACC, GND, K-line wires, attach emulator. Emulator must be in service mode: JUMPER 1 shorted. 2. Connect ANY K-line diagnostic adapter to vehicle diagnostic connector and launch EMULATOR CONFIGURATION UTILITY: 3. Choose COM port, write in desired ISN number, press button Store. Or – 4. For some ECU s it is possible to read ISN number directly from engine control unit. In this case select option ECU xxxxx , press Read. Software will try to read ISN. If successful, choose option EWS emulator and press button Store to save ISN number into emulator. 5. Disconnect emulator from K-line, remove JUMPER 1 and connect K output from emulator to DME(DDE) <-> EWS line. 6. Don t forget to short two starter relay wires (EWS connector)! 7. Car is ready to start. Package List: 1pc x Emulator E34 E36 E38 E39 E46 For BM-W EWS2 EWS3.2
